The FTTH Optical Receiver is designed for fiber-to-the-home (FTTH) CATV networks, delivering stable optical-to-RF signal conversion for both analog and digital television services. Featuring a low-noise GaAs amplifier, optical AGC technology, and optional WDM support for triple-play network integration, it provides reliable performance with low power consumption. Built with advanced surge and lightning protection, it is ideal for residential optical network terminals requiring dependable long-term operation.
SPECIFICATIONS
• Product Type: FTTH Optical Receiver
• Application: FTTH Fiber-to-the-Home, CATV & Triple-Play Networks
• Signal Conversion: Optical Input to RF Output
• Supported Signals: Analog & Digital CATV
• Amplifier Type: Full GaAs Low-Noise RF Amplifier
• Optical AGC Range: -3dBm to -12dBm
• Digital Optical Input Sensitivity: Up to -18dBm
• Analog Optical Input Sensitivity: Up to -10dBm
• WDM Support: Optional Built-In WDM (1490/1310/1550nm) for Single-Fiber Triple-Play Networks
• Optical Connector Options: FC/APC, SC/APC, FC/PC, SC/PC
• RF Connector: Customizable (Metric or Imperial)
• Power Consumption: Less Than 2W
• Power Supply: High-Efficiency Switching Power Supply
• Protection Features: Multi-Stage Lightning Protection, TVS Surge Protection & Optical Detection Circuit
• Features: Low Power Design, High Stability, High Reliability, Optical AGC, RF Signal Amplification & Single-Fiber Network Support
